| Performance | ||
|---|---|---|
| Sensitivity (±10 %) | 1.02 pC/(m/s²) | |
| Measurement Range | ±9810 m/s² pk | |
| Frequency Range (±5 %) | 5000 Hz | [2] |
| Resonant Frequency | ≥24 kHz | |
| Non-Linearity | ≤1 % | [1] |
| Transverse Sensitivity | ≤3 % | |
| Environmental | ||
| Overload Limit (Shock) | ±49050 m/s² pk | |
| Temperature Range | -54 to +482 °C | |
| Temperature Range | -54 to +482 °C | |
| Temperature Response | See Graph | [3] |
| Base Strain Sensitivity | 0.07 (m/s²)/µε | [3] |
| Radiation Exposure Limit (Integrated Neutron Flux) | 1 E10 N/cm² | |
| Radiation Exposure Limit (Integrated Gamma Flux) | 1 E8 rad | |
| Electrical | ||
| Capacitance | 630 pF | [3] |
| Insulation Resistance (900° F [482° C]) | >100 kohm | |
| Insulation Resistance (at 70° F [21°C]) | >100000000 Ohm | |
| Physical | ||
| Sensing Element | Ceramic | |
| Sensing Geometry | Compression | |
| Housing Material | Inconel | |
| Sealing | Hermetic | |
| Size - Hex | 5/8 in | |
| Size - Height | 25.4 mm | |
| Weight | 30 gm | [3] |
| Electrical Connector | 10-32 Coaxial Jack | |
| Electrical Connection Position | Side | |
