| Performance | ||
|---|---|---|
| Sensitivity (±20 %) | 247 pC/bar | |
| Sensitivity (±20 %) | 247 pC/bar | |
| Measurement Range | 1.4 bar | |
| Maximum Pressure (Total) | 27.6 bar | |
| Resonant Frequency | >50 kHz | |
| Frequency Response | 10 kHz | [2] [3] |
| Non-Linearity | ≤1 % FS | [1] |
| Environmental | ||
| Acceleration Sensitivity | .00069 bar/g | [5] |
| Acceleration Sensitivity | .00021 bar/g | [4] |
| Temperature Range (Continuous) | -70 to 530 °C | |
| Temperature Range (Receptacle) | -60 to 260 °C | |
| Temperature Response | See Graph | [4] |
| Hazardous Area Approval | See Manual | |
| Radiation Exposure Limit (Integrated Gamma Flux) | 1E8 rad | |
| Radiation Exposure Limit (Integrated Neutron Flux) | 1E10 N/cm² | |
| Electrical | ||
| Output Polarity (Differential) | Differential | |
| Capacitance (with cable pin - pin) | 165 pF | [4] |
| Resistance(Pin-Pin) (Room Temp) | ≥1000000000000 Ohm | |
| Resistance(Pin-Case) (Room Temp) | ≥1000000000000 Ohm | |
| Resistance(Pin-Pin) (986°F/530°C) | ≥50 kohm | |
| Resistance(Pin-Case) (986°F/530°C) | ≥100 kohm | |
| Physical | ||
| Sensing Element | UHT-12™ | |
| Sensing Geometry | Compression | |
| Housing Material | Nickel Alloy | |
| Sealing | Welded Hermetic | |
| Electrical Connector | 7/16-27 2-Pin | |
| Cable Type | Overbraided Hardline | |
| Weight (with clamp nut & cable) | 235 gm | |
| 40890-01 | |
|---|---|
| 40902-01 |
