| Performance | ||
|---|---|---|
| Sensitivity (+/-20 %) | 101.5 pC/bar | |
| Sensitivity (+/-20 %) | 101.5 pC/bar | |
| Measurement Range | 50 bar | |
| Maximum Pressure (Total) | 275.8 bar | |
| Resonant Frequency | ≥100 kHz | |
| Transverse Resonance | >15 kHz | |
| Frequency Response (±5.0 %) | 20000 Hz | [1] |
| Non-Linearity | ≤1 % FS | [2] |
| Environmental | ||
| Maximum Shock (Axial) | 19600 m/s² pk | [5] |
| Acceleration Sensitivity | 0.0069 bar/g | [4] |
| Acceleration Sensitivity | 0.00028 bar/g | [3] |
| Temperature Range (Continuous) | -70 to 650 °C | |
| Temperature Range (Receptacle) | -60 to 483 °C | |
| Temperature Response | See Graph | [3] |
| Radiation Exposure Limit (Integrated Neutron Flux) | 1E10 N/cm² | |
| Radiation Exposure Limit (Integrated Gamma Flux) | 1E8 rad | |
| Electrical | ||
| Output Polarity (Positive Pressure) | Positive | |
| Capacitance (with cable) | 250 pF | [3] |
| Insulation Resistance (Room Temp) | ≥1000000000000 Ohm | |
| Case Isolation (Room Temp) | ≥1000000000000 Ohm | |
| Insulation Resistance (1200°F / 650°C) | ≥50 kohm | |
| Case Isolation (1200°F / 650°C) | ≥50 kohm | |
| Physical | ||
| Sensing Element | UHT-12™ | |
| Sensing Geometry | Compression | |
| Housing Material | Nickel Alloy | |
| Sealing | Welded Hermetic | |
| Cable Type | Hardline | |
| Cable Length | 0.91 m | |
| Weight (with cable) | 57 gm | [3] |
| 060A25 | |
|---|---|
| 40890-04 |
