| Performance | ||
|---|---|---|
| Measurement Range (for ± 3V output) | 20685 kPa | |
| Sensitivity (±15 %) | 0.145 mV/kPa | |
| Maximum Pressure | 34475 kPa | |
| Resolution | 0.689 kPa | [2] |
| Resonant Frequency | ≥25 kHz | [3] |
| Rise Time (Reflected) | ≤20 µ sec | [3] |
| Low Frequency Response (-5 %) | 0.001 Hz | |
| Non-Linearity | ≤1.0 % FS | [1] |
| Environmental | ||
| Acceleration Sensitivity | ≤0.0014 kPa/(m/s²) | |
| Temperature Range (Operating) | -73 to +121 °C | [4] |
| Temperature Coefficient of Sensitivity | ≤0.054 %/°C | |
| Maximum Flash Temperature | 5538 °C | |
| Maximum Vibration | 19600 m/s² pk | |
| Maximum Shock | 98070 m/s² pk | |
| Electrical | ||
| Output Polarity (Positive Pressure) | Positive | |
| Discharge Time Constant (at room temp) | ≥500 sec | |
| Excitation Voltage | 20 to 30 VDC | |
| Constant Current Excitation | 2 to 20 mA | |
| Output Impedance | ≤100 Ohm | |
| Output Bias Voltage | 8 to 12 VDC | |
| Physical | ||
| Housing Material | 17-4 Stainless Steel | |
| Diaphragm | Invar | |
| Sealing | Hermetic | |
| Electrical Connector | Integral Cable | |
| Weight (without cable) | 130 gm | |
| Helium Flow Rate (at 1,500 psi) | 1.13 m³/hr | |
| Water Flow Rate (at 50 psi) | 4.5 L/min | |
| Cable Length | 1.2 m | |
| 065A15 | |
|---|---|
| 065A72 | |
| 070A08 |
