| Performance | ||
|---|---|---|
| Sensitivity (±15 %) | 0.870 pC/kPa | |
| Sensitivity (±15 %) | 0.870 pC/kPa | |
| Measurement Range | 690 kPa | |
| Maximum Pressure (static) | 20685 kPa | |
| Resonant Frequency | ≥55 kHz | |
| Rise Time (Reflected) | ≤9 µ sec | |
| Non-Linearity | ≤1 % FS | [1] |
| Environmental | ||
| Maximum Shock | 19620 m/s² pk | |
| Acceleration Sensitivity | .0028 kPa/(m/s²) | [2] |
| Temperature Range (Operating) | -240 to 345 °C | |
| Temperature Coefficient of Sensitivity | .072 %/°C | [2] |
| Maximum Flash Temperature | 1649 °C | |
| Maximum Vibration | 500 g pk | |
| Electrical | ||
| Output Polarity (Positive Pressure) | Negative | |
| Capacitance | 30 pF | [2] |
| Insulation Resistance (at room temp) | >100000000000 Ohm | |
| Insulation Resistance (at 650°F[345°C]) | >1000000000 Ohm | |
| Insulation Resistance (at room temp) | >100000000000 Ohm | |
| Physical | ||
| Sensing Element | Quartz | |
| Housing Material | 316L Stainless Steel | |
| Diaphragm | 316L Stainless Steel | |
| Sealing | Welded Hermetic | |
| Electrical Connector | 10-32 Coaxial Jack | |
| Weight | 20.3 gm | |
| Temperature Range | -65 |
| Temperature Range | -65 |
