| Performance | ||
|---|---|---|
| Sensitivity (±15 %) | .16 pC/kPa | |
| Sensitivity (±15 %) | .16 pC/kPa | |
| Measurement Range | 34475 kPa | |
| Maximum Pressure (Total) | 68950 kPa | |
| Resonant Frequency | ≥200 kHz | |
| Rise Time (Reflected) | ≤2.0 µ sec | |
| Non-Linearity | ≤1.0 % FS | [1] |
| Environmental | ||
| Maximum Shock | 98000 m/s² pk | |
| Acceleration Sensitivity | 0.0021 kPa/(m/s²) | [2] |
| Temperature Range (Operating) | -240 to +260 °C | |
| Temperature Response | See Graph | [2] |
| Maximum Flash Temperature | 1649 °C | |
| Maximum Vibration | 49000 m/s² pk | |
| Electrical | ||
| Output Polarity (Positive Pressure) | Negative | |
| Capacitance | 24 pF | [2] |
| Insulation Resistance (500°F/260°C) | ≥1000000000 Ohm | |
| Insulation Resistance (at room temp) | ≥1000000000000 Ohm | |
| Insulation Resistance (500°F/260°C) | ≥1000000000 Ohm | |
| Physical | ||
| Sensing Element | Quartz | |
| Sensing Geometry | Compression | |
| Housing Material | 17-4 Stainless Steel | |
| Diaphragm | 316L Stainless Steel | |
| Sealing | Welded Hermetic | |
| Electrical Connector | 10-32 Coaxial Jack | |
| Weight | 6.0 gm | |
| 060A03 | ｸﾗﾝﾌﾟﾅｯﾄ(5/16-24) |
|---|---|
| 060A05 | ｸﾗﾝﾌﾟﾅｯﾄ(M7) |
| 065A02 | ｼｰﾙﾘﾝｸﾞ |
| 065A05 | ｼｰﾙｽﾘｰﾌﾞ |
| 065A22 | |
|---|---|
| 065A08 |
| Output Polarity (Positive Pressure) | Positive |
| Output Polarity | Positive |
| Output Polarity (Compression) | Positive |
| 060A03 | Clamp nut, 5/16-24-2A thd, 1/4" hex, stainless steel |
| 060A05 | Clamp nut M7 x 0.75-6g thd |
