| Performance | ||
|---|---|---|
| Nominal Microphone Diameter | 1/2" | |
| Gain | -0.05 dB | [1] [3] |
| Frequency Response (±0.1 dB) (re 1 kHz) | 6.3 to 125000 Hz | |
| Frequency Response (-3 dB) (re 1 kHz) | <0.9 Hz | |
| Phase Linearity (<1 °) | 32 to 20000 Hz | [3] |
| Phase Linearity (-1 to +10 °) | 3.2 to 32 Hz | [3] |
| Electrical Noise (A-weight) | <2.8 µV | [3] |
| Electrical Noise (A-weight) | 1.7 µV | [1] [3] |
| Electrical Noise (Flat 20 Hz to 20 kHz) | <5 µV | [3] |
| Electrical Noise (Flat 20 Hz to 20 kHz) | 3 µV | [1] [3] |
| Distortion (3 V rms input at 1 kHz) | <-70 dB | [3] |
| Output Slew Rate | 2 V/µS | [1] |
| TEDS Compliant | Yes | [2] |
| Environmental | ||
| Temperature Range (Operating) | -40 to +80 °C | |
| Temperature Response | <0.05 dB | |
| Humidity Range (Non-Condensing) | 0 to 95 %RH | |
| Humidity Sensitivity | <0.05 dB | |
| Electrical | ||
| Excitation Voltage | 20 to 32 VDC | |
| Constant Current Excitation | 2 to 20 mA | |
| Impedance (Input) | 20 GOhm | [1] |
| Capacitance (Input) | 0.06 pF | [1] |
| Output Bias Voltage | 10 to 14 VDC | |
| Impedance (Output) | <50 Ohm | |
| Output Voltage (Maximum) | ±7 Vpk | |
| Physical | ||
| Housing Material | Stainless Steel | |
| Size - Diameter | 12.7 mm | |
| Size - Length | 80.7 mm | |
| Weight | 38 gm | |
| Electrical Connector | BNC Jack | |
| Mounting Thread (Microphone to Preamplifier) | 11.7 mm - 60 UNS | |
| ERC-16 | 校正データ |
|---|
| ERC-QC | 校正証明書 |
|---|
